NEW PRODUCT!
SM7QRF - 7" AHD Recording Quad Monitor
with an AHD IP69K Camera
The Verity SM7QRF system features a 7-inch AHD/CBVS hybrid monitor with a built-in Mobile Digital Video Recorder (MDVR). This monitor is compatible with both CBVS and AHD cameras and can support up to four cameras using its built-in multiplexer. MDVR records and stores video footage on a separate 256 GB SD card (sold separately). The recorded video is saved in the standard .avi format, ensuring compatibility with most common video players.
In addition, this system includes an AHD (1080P) heavy-duty rear backup camera (C001FM) with 18 IR night vision and an IP69K waterproof rating. The SM7QRF includes our ADD22H mount and (1) 65’ camera cable.
New C001FM AHD Camera
This camera captures clear AHD quality video to
help you see what's behind your truck.
The Monitor's Built-in MDVR records it all.
Our MK7QRF 7" LCD monitor has a built-in Quad multiplexer. Advanced Menu designed for true ease of use. Additionally, it offers recording and playback capabilities, enhancing safety and ease of use.
Key Features:
-
Available in multiple languages: default: English
-
Built-in speakers
-
Image flipping functionality (up, down, left, or right).
-
Recording and playback functionality.
-
Wide voltage range (12-24V)
MONITOR SPECIFICATIONS
(Monitor part #MK7QRF)
-
DVR built-in to the monitor (supports up to 256 GB SD)
-
SD card door with security screw
-
Screen size: 7-inch digital screen (16:9)
-
High Resolution: 1024 × 600 Pixel (RGB)
-
Video Format: CVBS / AHD (1080P)
-
System: NTSC Auto Select
-
Contrast: 800:1
-
Brightness: 450 cd/m2
-
Power supply: DC 12V
-
Operation temperature: -20C° ~ +60C°
-
Storage temperature: -25C° ~ +70°C
-
Monitor view angle: Horz. L (85) R (85) Vert. UP (85) DOWN (85)
-
4 camera inputs with shrink tube labeled trigger wires
-
Speaker built into the monitor
-
Auto blue screen if there is no signal on the activated channel.
This Product is not made in China.
Pictured with Optional ADD25F Mount
Optional Mounts
The AHD camera features an IP69K waterproof rating, while displaying wide 120-degree views behind the truck. 18 IR gives this camera great night vision capabilities for drivers who work late shifts.
CAMERA SPECIFICATIONS Part # C001FM
-
Image Sensor: 1/3 CMOS
-
TV System: NTSC / PAL
-
Format: AHD/1080P
-
Effective Pixels: 968(H) x 488(V)
-
Sensing Area: 4.8mm（H) x 3.67mm（V)
-
Resolution: 700 TVL
-
Night Vision: 18 IR LED
-
Minimum Illumination: 0.1 Lux (day), 0 Lux (with IR)
-
Microphone: Yes
-
White balance: AUTO
-
Backlight Compensation: AUTO
-
Power Supply: DC 12V
-
Waterproof rating: IP69K
-
Operating Temperature: -20℃-70℃
-
Storage Temperature: -30℃-80℃
